From large universities to community colleges, AFOPLUS's lc optical cable patchcord plays a crucial role. In a university's library, it connects the computer terminals to the central server, enabling students to access vast online resources. In a classroom with interactive whiteboards, it powers the seamless display of educational content. The OFNR Riser rating ensures it can be safely installed in the vertical shafts that run through campus buildings, meeting building code requirements. The OM1 multimode fiber's bandwidth can handle the concurrent use of multiple learning applications.

Connector A	LC PC Simplex	Connector B	LC PC Simplex
Fiber Count	1 Fiber	Fiber Grade	OM1
Fiber Mode	62.5/125um	Wavelength	850/1300nm
RoHS Compliancy Status	Compliant	Cable Type	Tight-Buffered
Cable Outside Diameter (OD)	2.0mm	Cable Jacket	PVC-OFNR (Riser)
Min. Bend Radius (Optical Fiber)	10mm	Min. Bend Radius (Fiber Cable)	10/5D (Dynamic/Static)
Connector Durability	500 times	Tensile Strength (Long/Short Term)	60/100N
Insertion Loss	≤0.3dB	Return Loss	≥35dB
Attenuation at 850 nm	3.0dB/km	Attenuation at 1300 nm	1.0dB/km
Operating Temperature	-20 to 70°C (-4 to 158℉)	Storage Temperature	-40 to 80°C (-40 to 176℉)
