AFOPLUS's sc sc multi mode fiber patchcord is a lifeline for multi-story hospitals and clinics. The OM3 50/125um fiber transmits critical data across floors with speed and accuracy, supporting life-saving decisions. Its high bandwidth handles telemedicine consultations and EHR system updates without lag. SC/PC connectors ensure stable connections between medical devices, nurse stations, and data centers, even in busy healthcare environments. Their precision design minimizes signal loss, crucial for reliable patient care. The OFNR Riser jacket??s fire resistance makes it safe for vertical risers in healthcare facilities. This multimode om3 fiber optical patch cord connects emergency rooms, operating theaters, and patient wards via vertical pathways, ensuring healthcare providers have instant access to vital information while protecting patients and staff.

Connector A	SC PC Simplex	Connector B	SC PC Simplex
Fiber Count	1 Fiber	Fiber Grade	OM3
Fiber Mode	50/125um	Wavelength	850/1300nm
RoHS Compliancy Status	Compliant	Cable Type	Tight-Buffered
Cable Outside Diameter (OD)	2.0mm	Cable Jacket	PVC-OFNR (Riser)
Min. Bend Radius (Optical Fiber)	10mm	Min. Bend Radius (Fiber Cable)	10/5D (Dynamic/Static)
Connector Durability	1000 times	Tensile Strength (Long/Short Term)	60/100N
Insertion Loss	≤0.3dB	Return Loss	≥35dB
Attenuation at 850 nm	3.0dB/km	Attenuation at 1300 nm	1.0dB/km
Operating Temperature	-20 to 70°C (-4 to 158℉)	Storage Temperature	-40 to 80°C (-40 to 176℉)
