Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible
Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible - Image 2
Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible - Image 3
Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible - Image 4

Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible

SKU: ASFP4MMM300MC

Price range: $38.22 through $49.00
Buy more to save

Transceiver Models
850nm 150m850nm 300m1310nm 10km MPO-12/APC1310nm 10km1310nm 20km1310nm 40km1310nm 80km
  • Shipping via DHL/FedEx |
  • 3 years Warranty
  • 30 Days Returns
  • 30 Days Exchange

Warranty
Providing industry-leading limited lifetime warranty. Read the table for details of all  products' warranty.

Returns & Exchange
Refunds will be received about  5 business days after the receipt of returned items. Items in stock  for replacement can be shipped within  1 business day. Read the full return policy for details.

  • Free Shipping on Orders over $99 for Whole USA
QuantityPrice
1 - 4 $49.00
5 - 49 $46.55
50 - 99 $43.12
100 + $38.22
QuantityPrice
1 - 4 $49.00
5 - 49 $46.55
50 - 99 $43.12
100 + $38.22
QuantityPrice
1 - 4 $49.00
5 - 49 $46.55
50 - 99 $43.12
100 + $38.22

Fiber Optical Transceiver|Optical Module 40G QSFP+ SR4 4x10GBASE-SR 850nm 300m MPO-12/UPC Multimode Cisco Compatible

Specifications

Operating at 850nm over multimode fiber, it provides a 300m transmission distance, 40G QSFP+ SR4 Fiber Optical Transceiver is ideal for short-range, bandwidth-hungry applications. The MPO Connector simplifies cabling, fitting snugly into busy racks. Its duplex design secures stable data flow. In data centers, it swiftly transfers critical backups. Compatible with QSFP+ form factor, the 40G optical module transceiver easily upgrades networks, ensuring a rapid 40G stream across 300m.
Form Factor QSFP+ Max. Data Rate 40Gbps
Wavelength 850nm Max. Cable Distance 300M
Connector MPO/MTP Media MMF
Transmitter Type 850nm VCSEL Receiver Type PIN
DOM Supported Commercial temperature range 0℃~70℃(32°F to 158°F)
TX Power -8.4~-2.4dBm Receive sensitivity < -10.3dBm
Power Consumption ≤1.5w Receiver Overload 2.4dBm
Core Size 50/125µm Extinction Ratio >3dB
Host FEC Supported Protocols IEEE 802.3ba, QSFP+ MSA, SFF-8436, SFF-8636
