Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode
Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode - Image 2
Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode - Image 3
Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode - Image 4

Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode

SKU: ASFPC22940KC

Price range: $82.33 through $141.00
Buy more to save

Transceiver Models
1350nm 40km1370nm 40km1330nm 40km1310nm 40km1290nm 40km1270nm 40km
  • Shipping via DHL/FedEx |
  • 3 years Warranty
  • 30 Days Returns
  • 30 Days Exchange

Warranty
Providing industry-leading limited lifetime warranty. Read the table for details of all  products' warranty.

Returns & Exchange
Refunds will be received about  5 business days after the receipt of returned items. Items in stock  for replacement can be shipped within  1 business day. Read the full return policy for details.

  • Free Shipping on Orders over $99 for Whole USA
QuantityPrice
1 - 4 $141.00
5 - 49 $133.95
50 - 99 $124.08
100 + $109.98
QuantityPrice
1 - 4 $105.55
5 - 49 $100.27
50 - 99 $92.88
100 + $82.33
QuantityPrice
1 - 4 $141.00
5 - 49 $133.95
50 - 99 $124.08
100 + $109.98
QuantityPrice
1 - 4 $141.00
5 - 49 $133.95
50 - 99 $124.08
100 + $109.98
QuantityPrice
1 - 4 $141.00
5 - 49 $133.95
50 - 99 $124.08
100 + $109.98
QuantityPrice
1 - 4 $141.00
5 - 49 $133.95
50 - 99 $124.08
100 + $109.98

Fiber Optical Transceiver|Optical Module Cisco Compatible CWDM 10G SFP+ 1290nm 40km Duplex LC/UPC Single Mode

Specifications

10G SFP+ CWDM fiber module is a workhorse for handling massive data volumes. Operating within the 1270 - 1370nm wavelength range under CWDM technology, the CWDM SFP+ module maximizes signal efficiency. The 40km transmission range makes it can connect network nodes across vast distances, such as linking different facilities in a large industrial complex. The Duplex LC/UPC interface ensure stable optical connections, while the single mode design minimizes signal degradation, guaranteeing accurate data reception.
Form Factor SFP+ Max Data Rate 10Gbps
Wavelength 1290nm Max Cable Distance 40km
Connector Duplex LC Media SMF
Transmitter Type CWDM DFB Receiver Type PIN
TX Power -1~4dBm Receiver Sensitivity <-16dBm
Power Consumption ≤2.5W Commercial Temperature Range 0°C to 70°C(32℉-158℉)
DDM/DOM Supported Protocols SFP+ MSA Compliant, CPRI, eCPRI
