With1390-1490nm wavelength range, this CWDM single mode sfp+ module supports data rates of up to 10G, ideal for high bandwidth applications. With a transmission distance of 10km, the fiber optical transceiver seamlessly connects network nodes across short to medium haul distances. Featuring duplex LC/UPC interface, 10G CWDM SFP+ transceiver integrates smoothly into existing networking infrastructures, enhancing overall network capacity, reliability, and scalability. Its compact, rugged design makes it suitable for deployment in diverse network environments, making it an essential component for modern, high-speed networks.

Form Factor	SFP+	Max Data Rate	10Gbps
Wavelength	1390-1490nm	Max Cable Distance	10km
Connector	Duplex LC	Media	SMF
Transmitter Type	CWDM DFB	Receiver Type	PIN
TX Power	-8.2~0.5dBm	RX Power	-14.4~0.5dBm
Power Consumption	≤1.5W	Receiver Sensitivity	<-14.4dBm
Modulation	NRZ	Extinction Ratio	>3.5dB
DDM/DOM	Supported	Commercial Temperature Range	0°C to 70°C(32℉-158℉)
Packaging Technology	TO	Protocols	SFP+ MSA Compliant, SFF 8472,SFF 8431,802.3ae, ITU-T G.652
