Boasting a 10G rate, the CWDM SFP+ fiber module is more than capable of coping with the demands of today's data-intensive applications. Whether it's binge watching ultra high definition shows on multiple devices simultaneously, engaging in lag-free online gaming, or collaborating on complex design projects in the cloud, it ensures a smooth experience. Operating within the 1510 - 1610nm range under CWDM, this 10G SFP+ transceiver sends signals far and wide, reaching network endpoints up to 20km away. The Singlemode design, along with the Duplex LC/UPC interface making it a go-to choice for those who prioritize stable and high-performance optical connections.

Form Factor	SFP+	Max Data Rate	10Gbps
Wavelength	1550nm	Max Cable Distance	20km
Connector	Duplex LC	Media	SMF
Transmitter Type	CWDM DFB	Receiver Type	PIN
TX Power	0~7dBm	RX Power	-14.4~0.5dBm
Power Consumption	≤1.5W	Receiver Sensitivity	<-14.4dBm
Modulation	NRZ	Extinction Ratio	>3.5dB
DDM/DOM	Supported	Commercial Temperature Range	0°C to 70°C(32℉-158℉)
Packaging Technology	TO	Protocols	SFP+ MSA Compliant, CPRI, eCPRI, ITU-T G.652
