As an high quality optical module, AOFPlus's CWDM SFP+ module plays an important role in optical communication. With a 10G data transfer prowess, it can shoulder the demands of today's data-greedy applications. Whether it's orchestrating a high-definition video conference with dozens of participants sharing screen content, or uploading hefty design files in a flash, the 10G SFP+ transceiver furnishes a seamless encounter. Operating within the 1390 - 1610nm range under CWDM, it dispatches signals across 40km distances. The single mode design and duplex LC/UPC interface further fortify its dependability, making it the preferred option for those hankering after stable and high-performance optical connections.

Form Factor	SFP+	Max Data Rate	10Gbps
Wavelength	1590nm	Max Cable Distance	40km
Connector	Duplex LC	Media	SMF
TX Power	-1~4dBm	RX Power	-16~0.5dBm
Transmitter Type	CWDM DFB	Receiver Sensitivity	<-15dBm
Power Consumption	≤2.5W	Extinction Ratio	>3.5dB
DDM/DOM	Supported	Commercial Temperature Range	0°C to 70°C(32℉-158℉)
Modulation	NRZ	Protocols	SFP+ MSA Compliant, SFF 8472,SFF 8431,802.3ae, ITU-T G.652
